M-Audio M-Track Solo 2-Channel USB Audio Interface

The M-Track Solo 2-channel USB audio interface delivers 24-bit/48kHz audio resolution in a super compact and easy-to-use format that is ideal for creating music on any Mac, PC or iOS device. This versatile interface is perfect for recording any type of sound source and features a single Combo Crystal Preamp with phantom power, making it compatible with any guitar or microphone. Plus, there is a stereo line input for connecting digital pianos, drum machines or any other stereo 1/4" device. M-Track Solo is completely powered by USB, removing the need for an external power supply and making it perfectly transportable for recording on the go. Throw it into your bag, grab a laptop and create your next podcast, song or mix anywhere you want.

At A Glance

• 2-channel USB recording interface for Mac and PC
• Combo input with Crystal Preamp for amazing audio quality
• +48V phantom power for connecting studio condenser microphones
• Dedicated instrument input for guitar or bass•
• Stereo line input for connecting digital piano, keyboard and more
• 1/8" headphone and RCA stereo outputs provide easy monitoring
• USB/Direct switch for listening to the input signal or the computer signal
• Software bundle, including: Pro Tools | First M-Audio Edition, MPC Beats, AIR Music Tech Xpand!2, Eleven Lite guitar amp plugin and 20 AVID plug-in effect

SpecificationsMic Input

• Frequency Response: 20Hz–20kHz (+0.1dB)
• Signal-to-Noise Ratio: 109dB (A-weighted)
• THD+N: 0.003% (min. gain, 0dBu out, A-weighted)
• Preamp: EIN-128dBu (max. gain, 40 ohm source, A-weighted)
• Gain Range: 0dB to +54dB

Line Input: (balanced 1/4" [6.35mm] TRS)

• Frequency Response: 20Hz–20kHz (+0.1dB)
• Sensitivity: -43dBu THD 0.002% (min. gain, 0dBu out, A-weighted)
• Gain Range:  -10dB to +44dB Instrument Input (unbalanced 1/4" [6.35 mm] TS)
• Frequency Response:  20Hz–20kHz (+0.1dB) THD+N0.005% (min. gain, 0dBu out, A-weighted)
• Input Impedance: 1 Mohm

Gain Range -10dB to +44dB Main Outputs, L and R (impedance-balanced 1/4" [6.35 mm] TRS)

• Frequency Response: 20Hz–20kHz (+0.1dB)
• Signal-to-Noise Ratio: 109dB (A-weighted)
• THD: 0.002% (0dBu out, A-weighted)
• Max Output Level: +4dBu

Headphone Output (1/4" [6.35 mm] TRS)

• Power: 60mW/Ch, 32 ohm
• Frequency Response: 20Hz–20kHz (+0.5dB)
• THD+N 0.02%:: (A-weighted)
• Signal-to-Noise Ratio: 100dB (A-weighted)

General

• Power USB bus-powered
• Dimensions: (WxDxH) 6.4” x 4.5” x 2.1”, 16.4 x 11.4 x 5.5 cm
• Weight: 0.66 lb. 0.30 kg
